For outdoor installation it is recommended to use a special cable for solar panels. Unlike conventional cables, solar panel cable has a special double-layer insulation, which protects its copper conductors from all types of environmental influences (rain, snow, UV radiation, temperature fluctuations).
Using this solar cable prevents possible problems during the operation of solar panels.
The cross-section of the cable should be chosen according to its length and the capacity of the solar panels, in order to minimise losses.
Technical data:
- Outer Ø: approx. 5.40 mm
- CU Weight kg/100m: 3.84 kg
- Conductor material: Copper, tin-plated
- Conductor class: Class 5
- Cable type: H1Z2Z2-K
- Conductor insulation material: Cross-linked polyolefin copolymer according to EN 50618
- Outer sheath material: Cross-linked polyolefin copolymer EN 50618
- Colour of sheath: Red
- Nominal voltage [V] AC: Uo/U 1/1kV, max. 1.2/1.2kV ; DC: 1.5kV, max.1.8/1.8kV
- Test voltage [V]: AC: 6.5kV DC: 15kv (5min).
- insulation resistance: > 750 MΩ x km at 20°C
- smallest bending radius fixed [xd]: 5 x d
- smallest bending radius moving [xd]: 15 x d
- operating temp. fixed min/max [C]: -40 °C to +90°C
- temperature at conductor: max. 125 °C
- fire behaviour: IEC EN 60332-1-2
- Standards EN 50618 / CPR EN13501-6
Scope of delivery:
- 1 x 500m solar cable 4 mm² red
| Product type: | Solar cable |
