H07V-K Cable – flexible copper conductor for fixed installation
The H07V-K cable is a flexible single-core conductor for standard indoor electrical installations. It is suitable for fixed installation in conduits, cable ducts, distribution boards and enclosed systems. Thanks to the fine-stranded class 5 copper conductor, the cable is easy to handle and can be installed cleanly even in tight spaces.
When a flexible installation cable is required for reliable wiring, the H07V-K is a proven standard solution. The cable combines good flexibility with durable PVC insulation and is suitable for many typical applications in switchgear, control systems and lighting installations.
Typical applications
- Wiring in switch cabinets and distribution boards
- Installation in conduits and cable ducts
- Lighting and control systems
- Protected fixed installation indoors
The H07V-K cable 450/750V is designed for fixed and protected installations. It is not intended for direct burial or permanent unprotected outdoor use.
Material and construction
The conductor consists of bare, flexible copper wire (class 5). This makes the H07V-K single core significantly more flexible than solid conductors and easier to install in many situations. The PVC insulation (TI1 quality) provides reliable protection in standard installation environments.
Technical data:
- Cable type: H07V-K
- Conductor: bare copper, flexible, class 5
- Insulation: PVC, TI1
- Rated voltage Uo/U: 450/750 V
- Operating temperature: +70 C ... -10 C
- Min. installation temperature: +5 C
- Max. short-circuit temperature: +160 C
- Bending radius: 4 x Ø
- Flame behavior: flame retardant according to EN 60332-1-2
- CPR class: Eca (EN 50575:2014 + A1:2016 and EN 13501-6:2016)
- Cross section: 16mm2
- Conductor diameter: approx. 5.0mm
- Insulation thickness: approx. 1.0mm
- Outer diameter: 7.0mm
- Electrical resistance max. at 20 C: 1.21 Ohm/km
- Current carrying capacity at 30 C: 68A
- Current carrying capacity at 50 C: 48A
Standards and marking:
The cable complies with common requirements for installation cables and is marked according to the following standards:
- EN 50525-2-31
- EN 60332-1-2
- HAR
- CE
- EAC
- UKCA
- RoHS compliant
Scope of delivery:
1x 20m single core cable 16mm2 H07V-K blue
