Coloured Pigtail Set 12x SC UPC OS2 Connector 2m

2m Coloured Pigtail Set 12x SC UPC OS2 Plug blue

General Information: This coloured pigtail set with 12 SC UPC connectors was developed for clean and well-arranged fibre optic installations in the OS2 range. Each pigtail is 2m long and comes pre-assembled ready for connection. This makes the set ideal for use in splice boxes, distribution panels, patch panels, and FTTH applications.

Function: The pigtails serve the structured and clear assignment of fibres in modern singlemode installations. Due to the coloured design of the individual fibres, the cables are significantly easier to distinguish during assembly. This simplifies the work in the distribution panel and ensures clean, fast, and traceable termination.

Application: The set is suitable for new installations, extensions, and repairs in fibre optic networks. Typical areas of application are splice boxes, distribution panels, patch panels, and FTTH applications. The 12 coloured 900µm coatings allow a clear assignment of the individual fibres and support a well-arranged installation.

Material: The LSZH material used is flame-retardant and halogen-free. As a result, the pigtail set is particularly suitable for areas where suitable fire behavior is required in addition to technical performance. The fibres feature coloured 900µm coatings: red, green, blue, yellow, white, grey, brown, violet, turquoise, black, orange, and pink.

Technology: The set consists of 12 pigtails with SC connectors, each 2m long. The pigtails are easy to strip up to 1m, thereby providing more flexibility during preparation and processing. The design complies with the DIN EN 50173-1 and IEC/ISO 11801 standards. Each cable is provided with a test report.

Conclusion: The 2m Coloured Pigtail Set 12x SC UPC OS2 Plug blue is a reliable solution for professional singlemode cabling with an SC UPC connection. It combines clear fibre assignment, LSZH design, and practical processing for splice boxes, distribution panels, patch panels, and FTTH applications.

Technical Data

Quantity:	12 pigtails
Connector:	SC UPC
Fibre Type:	OS2 Singlemode
Length:	2m per pigtail
Fibre Coating:	900µm
Colours:	red, green, blue, yellow, white, grey, brown, violet, turquoise, black, orange, pink
Strippability:	easy to strip up to 1m
LSZH:	flame-retardant and halogen-free
Application:	splice boxes, distribution panels, patch panels, and FTTH applications
Installation:	suitable for modern singlemode installations
Standards:	DIN EN 50173-1 and IEC/ISO 11801
Test Report:	each cable is provided with a test report

Show More Show Less

Scope of Delivery

1 x 2m Coloured Pigtail Set 12x SC UPC OS2 Plug blue

FAQ

When is an SC UPC OS2 Coloured Pigtail Set useful?

Such a set is useful when multiple fibres need to be cleanly prepared and clearly assigned in a singlemode installation. It is particularly practical in splice boxes, distribution panels, patch panels, and FTTH applications.

Why are the colours important in an SC UPC OS2 Coloured Pigtail Set?

The coloured 900µm coatings help to distinguish the individual fibres more quickly. This makes assembly clearer and reduces mix-ups during processing.
